e@syDrive? 4438 Kleinspannungs-Hochfrequenzumrichter mit Puls-Weiten-Modulation (PWM) zum Ansteuern von Synchron- und Asynchron-Motorspindeln und Kleinantrieben bis 3.800 VA. Parametrierung mit anwenderfreulicher PC-Software über RS232-Schnittstelle.
| Technical data | |
| Part-No. | 1005 0500 |
| Input voltage | 1 x 230 V AC (-23 % / +10 %) / 50/60 Hz |
| Output voltage | 0 - 230 V AC |
| Output current | 11 A (max. 16,5 A)/td> |
| Rated output power | 3.800 VA |
| Output frequency | max. 5.333 Hz |
| Modulation | pulse-amplitude modulation (PAM) |
| Brake resistor (internal) | 70 W |
| Power supply | integrated |
| Spindle reference DC | 4060 DC-S, 4060 DC-T, 4061 DC-S, 4061 DC-T, 4064 DC |
| Spindle reference AC | 4060, 4060 AC-T, 4060 ER, 4061 |
| Ambient temperature | 5 - 40 °C |
| Protection | IP 20 |
| EMC | EN 61800-3 |
| Weight | 4,5 kg |
| Supplement | including mating plug set |
| Commissioning | ? via Notebook (RS232) e@syDrive? 4438 control |
| Interfaces | 4 x Digital output 2 x Analog output 6 x Digital input 1 x Analog input |
| Connection of remote control | - |
