Kleinspannungs-Hochfrequenzumrichter mit Puls-Amplituden-Modulation (PAM) zum Ansteuern von Synchron- und Asynchron-Motorspindeln und Kleinantrieben bis 350 VA. Parametrierung mit anwenderfreulicher PC-Software über RS232-Schnittstelle.
| Technical data | |
| Part-No. | 1001 2768 |
| Input voltage | 70 V DC / 50 V AC |
| Output voltage | 3 x 0 - 45 V AC |
| Output current | 8 A |
| Rated output power | 350 VA |
| Output frequency | max. 4.000 Hz |
| Modulation | pulse-amplitude modulation (PAM) |
| Brake resistor (internal) | 60 W |
| Power supply | e@syDrive? 4428 |
| Spindle reference DC | 4015 DC, 4015 DC-G, 4015 DC-M, 4015 DC-R, 4025 DC-S, 4025 DC-T, 4033 DC |
| Spindle reference AC | 4010, 4025, 4026, 4029, 4033 AC |
| Ambient temperature | 0 - 50 °C |
| Protection | IP 20 |
| EMC | EN 61800-3 |
| Weight | 4,0 kg |
| Supplement | - |
| Commissioning | ??via Notebook (RS232) |
| Interfaces | ??2 x Relay output ??1 x Frequency output ??6 x Digital input ??1 x Analogue input |
| Connection of remote control | - |
