Bestell-Nr. 2001 6091 |
Part No. 2001 6091 |
||
Spannungsversorgung |
1 x 230 V AC (-10%/+10%) / 50/60 Hz |
Input voltage |
1 x 230 V AC (-10%/+10%) / 50/60 Hz |
Ausgangsspannung |
200 V AC |
Output voltage |
200 V AC |
Ausgangsstrom |
11 A (max. 20 A) |
Output current |
11 A (max. 20 A) |
Nennausgangsleistung |
3.800 VA |
Rated power output |
3,800 VA |
Ausgangsfrequenz |
max. 8.000 Hz |
Output frequency |
max. 8,000 Hz |
Modulationsart |
SVC, HSPAM/UF, HSBLOCK/FPAM, HSPWM |
Modulation type |
SVC, HSPAM/UF, HSBLOCK/FPAM, HSPWM |
Bremswiderstand (intern) |
22 Ohm / 50 W |
Brake resistor (internal) |
22 Ohm / 50 W |
Umgebungstemperatur |
5 - 40 °C |
Ambient temperature |
5 - 40°C |
Schutzart |
IP 20 |
Protection category |
IP 20 |
EMV |
EN 61800-3 |
EMC |
EN 61800-3 |
Gewicht |
3,5 kg |
Weight |
3.5 kg |
Versorgungsmodul |
integriert |
Power supply |
integrated |
Ausstattung |
inkl. Gegenstecker-Satz |
Supplement |
incl. mating connector set |
Konfiguration
|
via Computer-Interface (USB) via e@syDrive® 4638 control |
Configuration |
via computer interface (USB) via e@syDrive® 4638 control |
Schnittstellen |
5 x Digital-Ausgang 2 x Analog-Ausgang 9 x Digital-Eingang 2 x Analog-Eingang |
Interfaces |
5 x digital output 2 x analogue output 9 x digital input 2 x analogue input |
DC Spindelempfehlung |
4060 DC-S, 4060 DC-T, 4061 DC-S, 4061 DC-T, 4064 DC |
DC Spindle reference |
4060 DC-S, 4060 DC-T, 4061 DC-S, 4061 DC-T, 4064 DC |
AC Spindelempfehlung |
4060, 4060 AC-T, 4060 ER, 4060 ER-S, 4061 |
AC Spindle reference |
4060, 4060 AC-T, 4060 ER, 4060 ER-S, 4061 |
|
Änderungen vorbehalten |
|
Subject to change without notice |
