Niedervolt-Hochfrequenzumrichter als Tischversion mit einer Ausgangsspannung von bis zu 60 V zum Antreiben von synchronen und asynchronen Motorspindeln oder Motoren bis zu einer Drehzahl von 480.000 U/min.
Technical data | |
Part-No. | 2000 6670 |
Input voltage | 1 x 115 V (-10%) to 1 x 230 V (+10%) / 50/60 Hz |
Output voltage | 3 x 0 - 60 V AC |
Output current | 8 A (max. 14 A) |
Rated output power | 300 VA |
Output frequency | max. 6.666 Hz |
Modulation | pulse-amplitude modulation (PAM) |
Brake resistor (internal) | 33 Ohm / 10 W |
Power supply | integrated |
Spindle reference DC | |
Spindle reference AC | 4010, 4025, 4026, 4029, 4033 AC |
Ambient temperature | 5 - 40 °C |
Protection | IP 20 |
EMC | EN 61800-3 |
Weight | 3,7 kg |
Supplement | including plug set |
Commissioning | via Notebook (USB) |
Interfaces | 4 x Digital output 1 x Analogue output 9 x Digital input 2 x Analogue input 1 x Pulse output speed |
Connection of remote control |
